Rada Race Lab VR6 Engine Swap Harness Kit for ECUMaster EMU Black ECUs – Audi A4 S4 B5

We are proud to offer a “plug and play” harness kit for this popular engine swap. All harnesses will come with a startup/base file as well as direct startup support for your project. This is for OFF ROAD USE ONLY. While an engine can be tuned within the guidelines of emissions standards, standalone ECUs are not EPA/CARB approved for use on public roadways/highways.

Note:

• This harness is not pre-wired for air conditioning and also will not support ABS/ESP
• For both 12 valve and 24 valve engine variants
• FSI engines are not supported
• At this time we are not offering any “custom” harnesses OR harnesses for any other models
• All harnesses will be built to this spec

Features:

• “Club Level” wiring quality
• TXL automotive wire
• PET Braided sleeving (Techflex)
• Glue lined heat shrink
• Shielded “mil spec” trigger and knock sensor wiring
• Pre-wired for all necessary sensors/outputs for proper operation
• Crank and cam triggers
• Variable cam control (VVT)
• Coolant temperature sensor (green 4 pin “D” Shaped connector)
• GM intake temperature sensor
• OEM knock sensors (2)
• Drive by wire throttle body (OEM VR6)
• LSU 4.9 wideband sensor
• VW/Audi 4 wire igntion coils (coil on plug)
• Choice of injector connectors
• Flex fuel sensor connector
• Two additional pressure sensor connectors
• Pre-wired chassis connectors for OEM component function
• Tachometer
• Speedometer
• Coolant and oil temperature/level
• OEM fuel pump control
• Check engine light
• Additonal items
• Fan relay trigger wire (not terminated)

BUILT TO ORDER.   INQUIRE VIA EMAIL   [email protected]
